| Model (option) | QN3040L |
| X，Y，Z axis working area | 3000*4000*200mm |
| Guide rail | Taiwan 30 Square guide linear rail |
| X,Y structure | High-precision rack and pinion transmission |
| Z axis | ball screw |
| Control system | LNC control system |
| Whole structure | Cast steel |
| Max.engraving speed | 30m/min |
| Maxing cutting speed | 20m/min |
| Resolution | 0.01mm |
| Processing accuracy | <0.05mm |
| Wood holding | Vacuum absorption(by suction) |
| Competitive software | AutoCAD,Artcam,Photoshop,Type3,Artcut,Ucancam,powermill |
| Imagine format graphic | BMP,GIF,JPGE,PCX,TGA,TIFF,PTLCDR,DMG,DXF, |
| Spindle power | 9KW HQD ATC air cooling spindle |
| Spindle rotating speed | 6000-18000rmp/min |
| Tool magazine | Linear ATC system ,with 12 pieces of cutters |
| Diameter of cutter | φ3.175~φ20 |
| Driving system | servo system |
| Operate language | G code,plt,mmg,uoo,bmp,F/S |
| Working voltage | AC380V/50Hz or 220V |
| Running environment | Temperature:0-45;Humidity:30%~70% |
| With Optional parts | Vacuum worktable,dust collector |
| Machine parts |
9kw HQD air cooled spindle Leadshine servo motor and drive LNC control system Taiwan 30 squarer guide rail 11KW inverter equipment 11kw water cooled vacuum pump and vacuum worktable Automatic oil lubricating system automatic tool measurement 12 tool holder and collets Dust collector 3kw control box/wrench/brush user manual /design software |
