| Model (option) | QN6012L |
| X，Y，Z axis working area | 600*1200*200mm |
| Guide rail | Taiwan25 Square guide linear rail |
| X,Y structure | High-precision rack and pinion transmission |
| Z axis | ball screw |
| Control system | LNC control system Or MACH3 Or NK105 Controller |
| Whole structure | Cast steel |
| Max Machine idling speed | 70m/min |
| Max.engraving speed | 30m/min |
| Maxing cutting speed | 20m/min |
| Resolution | 0.01mm |
| Processing accuracy | <0.05mm |
| Wood holding | Vacuum absorption(by suction) |
| Competitive software | AutoCAD,Artcam,Photoshop,Type3,Artcut,Ucancam,powermill |
| Imagine format graphic | BMP,GIF,JPGE,PCX,TGA,TIFF,PTLCDR,DMG,DXF, |
| Spindle power | 9KW HQD ATC air cooling spindle |
| Spindle rotating speed | 6000-24000rmp/min |
| Tool magazine | Linear ATC system ,whit 6 pieces of cutters |
| Diameter of cutter | φ3.175~φ20 |
| Driving system | Leadshine servo system |
| Operate language | G code,plt,mmg,uoo,bmp,F/S |
| Working voltage | AC380V/50Hz or 220V |
| Running environment | Temperature:0-45;Humidity:30%~70% |
| With Optional parts | Vacuum worktable,dust collector |
| Machine parts |
9kw HQD air cooled spindle Leadshine servo motor and driver Taiwan 25 squarer guide rail 11KW inverter equipment 7.5KW Air cooled vacuum pump and vacuum worktable Automatic oil lubricating system automatic tool measurement Shimpo Reducer Dust collector 3kw control box/wrench/brush user manual /CD video/design software |
